IGBT

The principle of square wave inverter using IGBT switch devices was intreduced.

本文介绍了新型开关元件igbt管 作为逆变开关元件的交流矩形波逆变器的原理.

It piecewise modeled turn-on-off transient of IGBT, and simulated the static characteristics by curve fitting method.

模型分阶段模拟IGBT的开关瞬态过程, 并采用曲线拟合的方式实现对IGBT稳态特性的建模.

IGBT power modules, 18 KHZ inverter frequency, fast response time , high arc stability, almost spatter-free welding.

■采用igbt模块, 逆变频率达18KHZ,动态响应速度快 、 定性能好 、 接飞溅极小.

And the analysis is made on gate characteristics and switching process of IGBT.

介绍了全桥逆变电路的工作方式,探讨了IGBT的 栅极特性及动态开关过程.

Insulated Gate Bipolar Transistor ( IGBT ) as controllable switch, has been applied widely.

绝缘栅双极二级管 ( IGBT ) 作为一种可控开关, 获得了广泛应用.

Ones the PFC starts running the IGBT ( Q 2 ) gate supply becomes active.

当PFC开始运行时,IGBT ( Q2 ) 栅极电源变得激活.

Potential causes: Mechanical problem with pump, motor, or hydraulic system, malfunction in IGBT controller.

可能的原因: 泵, 电机或液压系统的机械故障, 或IGBT控制器误动作.

Familiar with PWM , PFM control chip, IGBT, MOSFET, high-frequency transformers and magnetic elements.

熟悉PWM、PFM控制芯片 、 IGBT, MOSFET等功率器件 、 高频变压器、电感等磁性元件.

By this filter the interfering signals are stopped from reaching the IGBT-based switch.

通过该滤波器,阻止干扰信号到达基于IGBT的开关.

The half-bridge inverter circuit is used IGBT as switch with the advantages of MOSFET and GTR.

主电路使用集MOSFET和GTR的 优点于一身的IGBT作为开关管,构成半桥逆变电路.

By the IGBT , the waveform acquisition strategy based on GPIB interface and JNI is put forward.

首先阐述了IGBT模型参数辨识的基本思想,以IGBT为 例,给出了采用JNI技术、基于GPIB接口的波形采集方案.

How to connect IGBT in parallel?

在IGBT并联 的情况下,应该如何连接?

A controller applied to IGBT inverter spot welding machine is introduced in this paper.

本文介绍一种应用于IGBT逆变式点焊机的点焊控制器.

IR 2130 was employed as gate driver to drive the H-bridge consisted of IGBT.

利用IR2130驱动器作为栅极驱动器,驱动用IGBT(绝缘栅双极晶体管)组成的单相H桥.
