voltmeter

WITH THE DRB IN VOLTMETER MODE, PROBE THE RR DECAY SOLENOID CONTROL CKT.

将DRB置为电压表模式, 测试右后衰减螺线管控制CKT.

The circuIt'shown in Figure 25 is the heart of an reading, rms calibrated AC voltmeter.

图25是一个平均值输出, 有效值刻度的交流电压表头放大电路.

An AC voltmeter ( V 2 ) is connected through Ch. 2 to a second signal source.

一个交流伏特计 ( V2 ) 通过通道2连接到另一个信号源.

To verify a switch card's specifications, the contact potential can be measured with a sensitive voltmeter.

若需验证某个开关卡的技术指标, 可利用灵敏的伏特计测得其接触电势.

A shunt ammeter can be modeled as a voltmeter with a resistor across the input.

分流型安培计可以看成是在其输入端跨接了电阻器的电压表.

WITH THE DRB IN VOLTMETER MODE, PROBE THE ABS SYSTEM RELAY CONTROL CKT.

用DRB的伏特计模式, 探测ABS系统继电器控制电路.

Close the channel and measure the voltage with a sensitive voltmeter.

闭合通道,利用一个灵敏的伏特计测量电压.

Make sure that the ac voltmeter shows no voltage.

确保交流伏特表显示无电压.

A voltmeter connected across A to B would read 10 volts.

两点间的电压表的读数应为10伏.

USING A VOLTMETER BACKPROBE THE PARK LAMP SWITCH OUTPUT CIRCUIT.

使用电压计反向测量停车指示灯的开关输出电路.

USING A VOLTMETER MEASURE THE FUSED B CKT.

用一个伏特计测量熔断的B电路.

WITH THE DRB IN VOLTMETER MODE , PROBE THE LR DECAY SOL CONTROL CKT.

使DRB处于电压计模式, 探查左后衰变电磁螺线管控制电路.

USING A VOLTMETER MEASURE FUSED IGN SW OUTPUT CKT AT THE RED CONN.

用伏特表测量红色接头处的熔断点火装置开关输出电路.

The testing system was composed of signal amplifer, digital voltmeter, data acquisition unite and computer.

由信号放大器 、 数字电压表 、 数据采集器、计算机等组成测量系统.

To monitor the output voltage, a voltmeter is connected in parallel with the load resistance.

为了监测输出电压, 将一个伏特计与负载电阻并联在一起.

And the excitation voltage and output were also fed the selector switch the digital voltmeter.

其激励电压和输出也通过选择开关接到数字电压表上.

USING A VOLTMETER MEASURE THE FUSED IGNITION SWITCH OUTPUT CKT ( CAV 3 ).

用伏特计测量熔断的点火开关输出电路 ( 3孔 ).

Then connect the voltmeter to the HI and LO output terminals of the switch card.

然后将伏特计连接到开关卡的HI和LO输出端子.

Ammeter, voltmeter, bridge and similar common methods are typical equipment types.

电流表 、 电压表 、 电桥以及类似的常见仪器都属于常用的设备.

The ohmmeter uses an internal current source and electrometer voltmeter to make the measurement.

欧姆计使用内部的电流源和静电计电压表来进行测量.

The voltmeter shows that the voltage between the two poles of the battery is 3.6 v.

电压计显示电池两端电压是3.6伏特.

The voltmeter leads are a known distance apart.

电压表的引线则按已知的距离放置.

This paper analysed the uncertainties of voltmeter in calibration by potentiometer.

分析了用电位差计检定电压表时的不确定度.

USING AN VOLTMETER, MEASURE THE VOLTAGE ACROSS THE RR WSS AND TERMINALS.

用电压计, 测量右后SS和 (−)端子.
